The patented Biohaus system is substrate-free technology producing optimal and efficient plant cultivation.
Contact us

45% less
labor-intensive system

Seed to Harvest cultivation system

Up to 80% yield increase

Utility cost savings
of up to 50%

The Ultimate Commercial Growing System

Plants Support:
Is part of GTS Aero unit and is fully customizable, to fit any style of growing.
Full Automation:
Cultivation Room is fully automated and can be controlled monitored by remote computer or a smartphone — Lighting Control, Climate Control, Irrigation Control, Fertigation Control, CO2 Injections and Safety Control, Hazard Control, Cultivation Journal, Cultivation Calendar
Air Supply/Return Ducts:
Air is supplied through bottom ducts into air distribution sleeves. Air is returning through top ducts for conditioning.
Grow Table:
GTS Aero is Commercial Aeroponic Cultivation System. It holds 8-36 plants, with canopy up to 20 sq ft per unit. Multiple layouts available, to fit room any size and any lighting footprint.
Nutrient Day Tank and optional Treatment Tank:
Day Tank holds nutrient solution for Irrigation. Nutrient solution recirculates. Treatment Tank is optional. It can be used in commercial setting to apply particular substance on roots, without draining and changing Day Tank.
Irrigation Pump and Back-up Pump:
Irrigation Pump delivers nutrient solution to plans and is fully automatic. Irrigation line is always pressurized. If drop of pressure detected, the Back-Up Pump automatically kicks-in and sends a notification to operator. Back-Up Pump will provide normal irrigation until Main Pump is back online.
Fertigation (optional):
Fertigation system automatically mixes fresh nutrient solution, drains and fills Day Tank.
Solution Return:
After irrigation, nutrient solution drains into this container, Ph/C/Temp are measured, solution being filtered and sent back to Day Tank.
Climate Control:
Controls Climate and CO2 injections in the room. Cooling, Dehumidification, Humidification, CO2 injection, Air circulation.
Commercial Grade:
GTS Aero is Commercial Grade Cultivation System. It has been designed and tested for commercial application. System has significantly less possibilities of catastrophic failures.
Access Pass:
16 - 24 inch, depends on layout.
Legs:
GTS Aero units include legs and stands directly on the floor. Not requiring expensive metal benches. However, GTS Aero can be mounted on rolling benches, if desired
Air Distribution Sleeves:
Located under tables and supply conditioned air to the room. Our proprietary Air Distribution System designed to provide even distribution of air and airflow in the canopy. Keeping optimal parameters 24/7.

Multiple system layouts to fit any room size and any light footprint

Plant trellising is a part of the grow unit and has multiple configurations. This holds the canopy of larger plants in place.
Plant trellising
01
Different lids available. GTS Aero V36 lid holds up to 36 plants. Ideal for vegetative growth.
Lid — 36 plants
02
Different lids available. GTS Aero F8 lid holds 8 medium to large plants. Ideal for fruiting/flowering cycle.
Lid — 8 plants
03
High pressure foggers create extremely fine mist supplying roots with nutrients.
High pressure foggers
04
Unique Labyrinth Channels designed for movement of the nutrient solution and root growth.
Unique Channels
05
Aeration stone provides filtered fresh air to root zone, keeps positive pressure in root chamber - not allowing pests into root chamber. And it aerates the nutrient solution.
Aeration stone
06

GTS Aero.
Scalable solution
for commercial
cultivation

The GTS Aero System utilizes the best solutions from other cultivation
methods:

In the Biohaus Grow Unit, roots serve as it’s own substrate, retaining necessary moisture and facilitating slow aeration. The gradual air exchange system creates an excellent natural aeration environment facilitating uninterrupted functions of roots and their symbiotic organisms.
Compared to soil cultivation and «Drain to Waste» hydroponics, there is a 95% savings of water with our recirculation irrigation system. This minimal runoff produces an ecological benefit to the environment.
This system utilizes a mechanism in which the nutrient solution is fed directly to the root zone. The solution is delivered periodically by high-pressure diffusion, gradually permeating the entire mass of loosely interlaced roots. Any excess solution reaches the inclined base where the entire root mass is located. This system also allows for the remainder of the used solution to be effectively washed away, ensuring the roots receive fresh, nutrient-rich food.
The inclined base contains low, vertical ribs resembling a labyrinth. Once the solution has permeated the root mass it will flow through the entire labyrinth, completely draining in approximately ten minutes. At that time, fresh nutrient-rich solution is released. Constant aeration in the root mass ensures overwatering never occurs as the solution moves through the root zone.
Removing the root observation lid grants immediate access to the root zone, facilitating assessment of plant health. This immediately allows for any needed action to be taken.
Comparatively, substrate cultivation may take two to three days for any changes in the health of the plant to be revealed in the canopy.
Innovative
Substrate-Free Cultivation
System
Innovative Nutrient Solution Feeding System
Access and Observe the Root Zone without Compromising Plants
In the GTS Aero unit, roots serve as it’s own substrate, retaining necessary moisture and facilitating slow aeration. The gradual air exchange system creates an excellent natural aeration environment facilitating uninterrupted functions of roots and their symbiotic organisms.
Compared to soil cultivation and «Drain to Waste» hydroponics, there is a 95% savings of water with our recirculation irrigation system. This minimal runoff produces an ecological benefit to the environment.
This system utilizes a mechanism in which the nutrient solution is fed directly to the root zone. The solution is delivered periodically by high-pressure diffusion, gradually permeating the entire mass of loosely interlaced roots. Any excess solution reaches the inclined base where the entire root mass is located. This system also allows for the remainder of the used solution to be effectively washed away, ensuring the roots receive fresh, nutrient-rich food.
The inclined base contains low, vertical ribs resembling a labyrinth. Once the solution has permeated the root mass it will flow through the entire labyrinth, completely draining in approximately ten minutes. At that time, fresh nutrient-rich solution is released. Constant aeration in the root mass ensures overwatering never occurs as the solution moves through the root zone.
Removing the root observation lid grants immediate access to the root zone, facilitating assessment of plant health. This immediately allows for any needed action to be taken.
Comparatively, substrate cultivation may take two to three days for any changes in the health of the plant to be revealed in the canopy.
Innovative Substrate-Free Cultivation
System
In the Biohaus Grow Unit, roots serve as it’s own substrate, retaining necessary moisture and facilitating slow aeration. The gradual air exchange system creates an excellent natural aeration environment facilitating uninterrupted functions of roots and their symbiotic organisms.
Compared to soil cultivation and «Drain to Waste» hydroponics, there is a 95% savings of water with our recirculation irrigation system. This minimal runoff produces an ecological benefit to the environment.
Innovative Nutrient Solution Feeding System
This system utilizes a mechanism in which the nutrient solution is fed directly to the root zone. The solution is delivered periodically by high-pressure diffusion, gradually permeating the entire mass of loosely interlaced roots. Any excess solution reaches the inclined base where the entire root mass is located. This system also allows for the remainder of the used solution to be effectively washed away, ensuring the roots receive fresh, nutrient-rich food.
The inclined base contains low, vertical ribs resembling a labyrinth. Once the solution has permeated the root mass it will flow through the entire labyrinth, completely draining in approximately ten minutes. At that time, fresh nutrient-rich solution is released. Constant aeration in the root mass ensures overwatering never occurs as the solution moves through the root zone.
Access and Observe the Root Zone without Compromising Plants
Removing the root observation lid grants immediate access to the root zone, facilitating assessment of plant health. This immediately allows for any needed action to be taken.
Comparatively, substrate cultivation may take two to three days for any changes in the health of the plant to be revealed in the canopy.

Large Scale Features. Multiple system layouts to fit any room dimensions and lighting footprint

Proven commercial scale cultivation technology. Scalable industrial solutions.
Multiple system layouts to fit any room dimensions and lighting footprint.
Proven commercial scale cultivation technology. Scalable industrial solutions.
Multiple system layouts to fit any room dimensions and lighting footprint.

Complete Cultivation System - we provide equipment that covers all cultivation needs from Seed to Harvest.

Aero V36
GTS Aero V36 — unit holds up to 36 plants and provides support for the canopy.

Veg, Clones, Small plans

up to 36 plans

Cultivation Systems
Aero F8
GTS Aero F8 — unit for 8 medium to large plants and support for the canopy.

Flowering, Fruiting, Mid-Large plants

up to 8 plants

Cultivation Systems
Aero M8
GTS Aero M8 — holds up to 8 large plants and provides support for the canopy.

Mothers, Large Plants

up to 8 plants

Cultivation Systems
Catalog
Find more products in our online shop. Fill in the form and we contact you to get more details.
products
Go to catalog
show more
Grow Tech Solutions provides wide range of services.
We can help with
following:
Cultivation System Design, Irrigation/Fertigation Design, Architectural Design, MEP Design, Design Project Management, Permit Application, City/State License Application, Equipment Sizing and Procurement, Construction Management, Bidding Managements, Value Engineering - we can save you money on existing design, Occupancy Permit, Facility SOPs, Compliance, IPM.
Feedback from our customers
GTS: Patrick, what's your favorite feature of GTS system?
Patrick S. NorCal: I love being able to open the lid and have access to roots. See what color they are, what size and shape, you can tell a lot about the plant looking at roots Genius!
GTS: Garry, you switched to GTS System because your Hydroponics System was very labor intensive. How is your labor cost now?
Garry M. California: labor costs are 30% down and production is 50% up :-)
GTS: Victor, what can you say about the System and your plants?
Victor G. Nevada: The system is definitely next gen! Using it immediately noticed rapid growth, incredible development of side branches and better overall plant health.
GTS: Larry what is the biggest benefit you got from utilizing GTS system?
Larry L Grower: From 4 cycles a year in soil to 6 cycles with your system!
GTS: Michael, what do you think about GTS System?
Michael H. SoCal: In my option, this is the only aeroponics system suitable for commercial cultivation of fruiting plants.
Feedback from our customers
GTS: Patrick, what's your favorite feature of GTS system?
Patrick S. NorCal: I love being able to open the lid and have access to roots. See what color they are, what size and shape, you can tell a lot about the plant looking at roots Genius!
GTS: Garry, you switched to GTS System because your Hydroponics System was very labor intensive. It's been how is your labor costs?
Garry M. California: labor costs are 30% down and production is 50% up :-)
GTS: Larry what is the biggest benefit you got from utilizing GTS system?
Larry L Grower: From 4 cycles a year in soil to 6 cycles with your system!
GTS: Victor, what can you say about the System and your plants?
Victor G. Nevada: The system is definitely next gen! Using it immediately noticed rapid growth, incredible development of side branches and better overall plant health.
GTS: Michael, what do you think about GTS System?
Michael H. SoCal: In my option, this is the only aeroponics system suitable for commercial cultivation of fruiting plants.

Whether an existing facility or new construction, we can help you lower costs and increase profits. Contact below to see how we can help!
